■Ice Making Principle
liquid bottle
filter
reverse solenoid valve
compressor
tube
evaporator
condenser
~
M
■Structure brief drawing
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
12
13
14
11
1. water tank 2. ice storage box 3. water tray 4. evaporator
5. insulation layer 6. fan motor 7. compressor 8. socket
9. water pump motor 10. drain outlet 11. handle grip 12. ice basket door
13. front panel 14. shell
