TREELINE FDR0350AS - Page 6

5
Step 5
Slide spinner bracket onto shaft and secure
with four M6 x 12 mm hex bolts and washers.
Step 6
Attach legs to hopper using sixteen M6 x 15
mm hex bolts and washers.
Note: Make sure the holes in the bottom of the
legs are oriented with the sides of the hopper
as shown.
