TREEPOD STAND INSTRUCTION MANUAL - ENGLISH
INSTRUCTIONS:
PARTS
ASSEMBLY:
2. Lay out all of the parts
identifying the sections of each
leg.
2
3. Lay the Topper on the ground
with prongs up and insert the
female end of a Top Leg Pole into
the Topper. Insert bolts in the pre-
drilled holes along top leg section
from the inside. Place a washer
and lock washer onto the bolt from
the outside. Then screw on a nut
cap. Tighten using the wrench to
secure. Repeat with the other two
Top Leg Poles.
3
1 Topper
1 Ring with Webbing
24 Hex Bolts
24 Cap Nuts
1 Wrench
3 Middle Leg Poles
(poles with a female end and male end)
3 - Top Leg Poles
(2 female ends)
24 Washers 24 Lock Washers
3 - Base Leg Poles
(poles with a male end and capped end)
3 - Adjustment Poles
(poles with a female end and male end)
1. Find solid flat ground area and make sure there are no soft spots or other obstacles on the
ground that could make the TreePod Stand unsteady or at an angle.
WASHER LOCK WASHER NUT CAP
3 - Pole Covers
