Trek 2023 FX+ - Mudguards and rack installation

2023 FX+ / Dual Sport+
9
Mudguards and rack (aermarket on Dual Sport+)
1
2
3
7
18
7
9
5
16
11
15
16
13
15
12
8
4Nm.
3Nm.
3Nm.
4Nm.
10
5
15
5
16
3Nm.
15
17
4Nm.
4
1
2
10
11
15
16
3Nm.
14
6
19
1
Stay clips
5258253
2
Damping rubbers
3
Mudguard stay (330 mm) – W1049503
4
Mudguard stay (310 mm) – W5254584
5
Mudguard strut – W600320
6
Spacers (12x5 mm) – 504881
7
Spacers (15x5 mm)
5260275
8
Spacer (15x15 mm)
9
Slot cover – W1049294
10
Mudguard stay mounts – 5258260
11
Knurled washers
12
Locknut (M5)
5260273
13
Bolt (M5x30 mm)
14
Bolt-nuts – W317707
15
Flat washers (M5)
16
Bolts (M5x14 mm)
5260274
17
Bolts, M4 hex
18
Bolt, M3 hex (M5x25
mm)
19
Rack (70 mm wide) – W597296
