2023 Fetch+ 4
12
Steering Dr ivetrain Routing Battery Headsets Frame Accessor ies
Routing: instructions
Rear headset
1. Route all handlebar cables/wires/hoses down
through the frame — except the front brake. Use the
current housing as a guide when pulling a new one
through.
4
8
5
6
7
2. Route the cables through the frame. Remove the
steering column cover (see page 1) and non-driveside
motor cover (see page 6) to access the cables easier.
NOTE: Remove the motor to have additional access
to the cables (see page 6).
3. Install the cable guides (17).
4
8
5
6
7
7
Speed sensor
Route the wire from the back — through the chainstay — to
the drive unit.
1
2
