TREND HT series - HT;ST Sensor Disposal (WEEE Directive)

HT/ST Installation Instructions - Sheet 2
HT/ST Space Humidity and Temperature Sensor Installation Instructions TG200921 Issue 1/B 30/08/06
2 - 2
Screw board in place
6
2.1 Maintenance (continued)
Assemble unit
7
Install new sensor tip
5
J P R 4
L P 2 - P W R
T H
I 2 - N / T H
I 1 - N
I 1 - P
E A R T H
hold sides of sensor
tip near base of
sintered filter
ACC/HT/SENSOR TIP for HT/ST
J P R 4
L P 2 - P W R
T H
I 2 - N / T H
I 1 - N
I 1 - P
E A R T H
J P R 4
L P 2 - P W R
T H
I 2 - N / T H
I 1 - N
I 1 - P
E A R T H
backplate
‘click’
Switch on supply
8
O
I
I Q
I Q
Δ T
Test system
9
Temperature
Humidity
Δ H
HT/ST Space Humidity and Temperature Sensor Installation Instructions TG200921 Issue 1/B 30/08/06
2 - 3
Installation Instructions - Sheet 2 HT/ST
2.2 Disposal
WEEE Directive :
At the end of their useful life the packaging
and product should be disposed of by a
suitable recycling centre.
Do not dispose of with normal household waste.
Do not burn.
