12' X 14' HONOLULU PAVILION USER GUIDE 29
Part Description Qty Part Description Qty Part Description Qty
J x 4 K
x 4
K1
x 4
Cover Plate Corner Gap Cover Cover Plate
L x 1 M
x 1
N
x 4
Roof Connector Roof Connector Cover Plate
P x 6 Q
x 2
Q1
x 4
Cover Plate Roof Panel Roof Panel
Q2 x 4 R
x 2
R1
x 4
Roof Panel Roof Panel Roof Panel
R2 x 4 S
x 20
T
x 4
Roof Panel Roof Panel Plug Mosquito Netting
V x 60
Hook
