Trevi 19268 - Parts List

12' X 14' HONOLULU PAVILION USER GUIDE 28


Part Description Qty Part Description Qty
A x 4 B
x 4
Column Base
C x 2 C1
x 2
Crossbeam Crossbeam
C2 x 2 C3
x 2
Crossbeam Crossbeam
D x 4 E
x 6
Roof Bar Roof Bar
F x 4 F1
x 4
Support Bar Support Bar
F2 x 4 F3
x 4
Support Bar Support Bar
F4 x 4 G
x 2
Support Bar Finishing End Bar
G1 x 4 G2
x 4
Finishing End Bar Finishing End Bar
H1 x 4 H2
x 4
Corner Bracket Corner Bracket
