XR 8A15
English
CHARGING
The speaker must be recharged when switched off.
1. Using the supplied USB/Micro USB cable, connect the side with the Micro USB jack to the
micro-USB jack (7) and the other end to the USB port of a PC or USB charger (5V, 1A not
included);
2. Led indicator (8) will light up red to indicate the charging status, after charging it will off.
Note: when the battery is low, the guide voice will reproduce the warning message “Lower
Battery, please recharge” a few times before the device turns off automatically.
BASIC OPERATION
Long pressing button(1) to turn On the speaker.
Press button (1) to choose from:
- Bluetooth mode.
CONTROLS
1. Power On/Off Switch
2. Play/Pausa
3. Next/ Volume+
4. Prev/ Volume-
5. TF Card Slot
6. AUX IN
7. Charging port
8. Charging indicator:
Blue: In playback Mode
Red: On during charging, Off when
charging is complete.
10. LED control button
11. Carry Strap Hole
