XR 8A20
English
CONTROLS
CHARGING
The speaker must be recharged when switched off.
1. Using the supplied USB cable, connect the side with the microUSB jack to the microUSB
jack (7) and the other end to the USB port of a PC or USB charger (5V/1A not included).
2. Led indicator will light up red to indicate the charging status, after charging it will off.
Note: When the battery is in the process of exhaustion, the device will emit a warning sound
for a few times before it shuts down automatically.
MIC
1 2 3 4
6 7 9 105 8
1. Volume- / Previous Track button
2. MODE button
3. Play / Pause button
4. Volume+ / Next track button
5. USB input
6. microSD memory input
7. Micro USB socket for charging with LED
indicator:
Blue: in music playback
Red: on during charging, it turns off
when charging is completed
8. Microphone
9. AUX IN input
10. Power On/Off
