Tri-Tronics Ultrasonic Clear Label Sensor - Sensor Specifications and Connections; Technical Specifications; Pushbutton Controls; Output Timers and Connector Types

www.ttco.com • 800-237-0946
2-112
2
Specialty Application Photoelectric Sensors Clear Label Sensor
SUPPLY VOLTAGE
• 12 to 30 VDC
• Polarity Protected
Note: For use in Class 2 Circuits
CURRENT REQUIREMENTS
• 95mA @ 12 VDC, 45mA @ 30 VDC
DIGITAL OUTPUTS
• (1) NPN and (1) PNP open collector
output 150mA Max; <2V Residual
Voltage
(Note: On CLSC-1M8, NPN & PNP are
software selectable).
• All outputs are continuously short
circuit protected
REMOTE AUTOSET INPUT
• Momentary sinking or sourcing
input;
1.2mA max; Software Selectable
DIAGNOSTIC INDICATORS
• OLED Graphic Display - Includes
Contrast Indicator, Numerical
Display, Set Point and Trigger Point,
and all sensor options and modes.
• Red LED Output Indicator–
Illuminates when the sensor’s
output transistors are “ON”.
Note: If output LED flashes on power
up, a short circuit condition exists.
PUSHBUTTON CONTROL
• Three (3) push button controls
• Gap (for Gap AUTOSET)
• Label (for multi-layered labels)
• Menu (for accessing Options)
HYSTERESIS
• Dynamic – adjusted by AUTOSET
RESPONSE TIME
• 200µs
REPEATABILITY
• 125µs
AMBIENT TEMPERATURE
• 4°C to 50°C (39°F to 122°F)
RUGGED CONSTRUCTION
• Chemical resistant, high impact
Aluminum housing
• Waterproof ratings: NEMA 4X, 6P
and IP65
• Conforms to heavy industry grade
CE requirements
THRESHOLD SET
• 1-Point, 2-Point, or Dynamic
AUTOSET; manually or remotely.
THRESHOLD ADJUST
• Manual or AUTO Adjust
OUTPUT TIMERS
• On Delay, Off Delay, One Shot, or
Debounce (Advanced Option,
software selectable).
CONNECTOR
• M12 5-Pin, M8 4-Pin, or 6’ (1.8m)
Shielded Cable
RoHS Compliant
Product subject to change without notice
Specifications
(2)
(2)
30 VDC
12 To
M8 Wiring
Output
NPN (SINKING) INPUT ACTIVATED BY CONNECTING TO NEGATIVE
PNP (SOURCING) INPUT ACTIVATED BY CONNECTING TO POSITIVE
(2) -
(1) -
NPN (SINKING) OUTPUT LOAD TERMINATED TO POSITIVE
PNP (SOURCING) OUTPUT LOAD TERMINATED TO NEGATIVE
(1)
LOAD
Pos
Remote
Autoset
Neg
Brown* (1)
Red
Green
Black* (4)
W hite
White* (2)
Blue* (3)
Black
LOAD
LOAD
Blue
Gray* (5)
Pos
NPN
(Sink)
PNP
(Source)
Neg
Remote
Autoset
30 VDC
12 To
M12 and Cable Wiring
Brown (1)
Black (4)
White (2)
Blue (3)
Wht
Load
NPN
Load
PNP
(2)
Brn
(1)
Blk
(4)
Blu
(3)
Gry
(5)
0.250"
[6.3 m m]
0.551"
[14 .0m m ]
0.360"
[9.1 m m]
2.767"
[70 .3m m ]
0.767"
[19.5mm]
3.113"
[79.1mm]
0.158"
[4.0mm]
3.893"
[98 .9m m ]
2X Ø0.205"
[2X 5.20mm]
OUTPUTOUTPUT
S
O
T
U
A
T
E
A
G
P
A
L
B
E
L
E
N
M
U
OUTPUT
S
O
T
U
A
T
E
A
G
P
A
L
B
E
L
E
N
M
U
S
O
T
U
A
T
E
A
G
P
A
L
B
E
L
E
N
M
U
4.522"
[114.86m m ]
4.332"
[110.03m m ]
4.181"
[106.20m m ]
Brown (1)
Black (4)
White (2)
Blue (3)
LOAD
LOAD
Pos
NPN
(Sink)
PNP
(Source)
Neg
30 VDC
12 To
CLSC-1M8LE Wiring
M8 & M8LE
MODELS
M12
MODELS
CABLED
MODELS
M8 Male
Connector
1 - Positive
2 - Remote AUTOSET
3 - Negative
4 - Output
4
3
2
1
* - Sensors with connectors
1 - Positive
2 - NPN
3 - Negative
4 - PNP
5 - R em o t e AUTOSET
M12 Male
Connector
2
3
1
4
5
M8LE Male
Connector
1 - Positive
2 - NPN
3 - Negative
4 - PNP
4
3
2
1
0.472"
[12.0m m ]
0.360"
[9.1mm ]
2X 6-32 Mounting
Holes, 0.150"
[3.8m m ] D eep
M8 & M8LE
MODELS
M12 MODELS
1.441"
[36 .6m m ]
0.850"
[21 .6m m ]
1.944"
[49 .4m m ]
2.022"
[51.4mm]
0.676"
[17.2mm]
1.110"
[28.2mm]
Connections and Dimensions Ultrasonic Clear Label Sensor
NOTE: Side and bottom mounting holes
are compatible with LER models.
