Connections
For optimal sound reproduction, we suggest that you choose a loudspeaker cable of high quality to
connect your amplier to your TRIANGLE loudspeakers. You should use cables of the same lengh
for the left and right channels and take special care to respect the + and - polarity for each channel.
Don’t forget to strip the cables if it’s necessary.
Bi-amplication and bi-wiring
For those wishing to iprove their listening system further, it is possible to use a bi-amplication or
bi-wiring.
With bi-amplication, interference between the woofers and other drivers is totally eliminated, as
each one is driven by its own amplier. It is compulsory to use identical ampliers to conserve the
uniformity of the loudspeaker.
To do this, remove the terminal jumpers and use two stereo ampliers. On the speakers, the upper
terminals are the signal inputs for midrange and treble. The lower terminals are the signal inputs
for bass. Use one amplier to feed the bass, and the second for the midrange and treble (see the
diagram below).
Instead of two ampliers, you can use a single amplier if it is equipped with two sets of speakers A
and B. Both sets should be selected. This is bi-wiring and not bi-amplication.
For further informations concerning your system, please consult our website :
http://trianglehi.com/
A
B
