The GHV 900 Series i
s a low noise coaxial House Distribution Amplifier, for use
in smaller to medium CATV distribution networks in multi dwelling houses.
The GHV 900 Distribution Amplifier Series share a modular design with return
path all-on-board for easy setting and installation
Rotary switches and jumpers provide for readable, easy and reproducible setting
of attenuation and equalization, maintaining a non-breakable signal path down-
and upstream to avoid down-time.
• Cost optimized 1 GHz technology
• Downstream 20 to 40 dB amplification / High output level
• Adjustable attenuation and equalization settings in 1dB steps
using rotary switches and jumpers.
• Switchable operation modes: VHF Band I (RC=OFF) or 5-65 MHz Return
Path (RC=ON)
• Selectable Return Path: On/Off, Active/Passive.
• Upstream switchable amplification ( except GHV 920 )
• All-on-board return path technology, all features available
without module.
• Optional Automatic Return-path Activation (ARA) module connector.
(Switchable return path blocker for Noise suppression)
• All connectors are F-connector female, individually mounted.
• -20dB input- and output- Test connectors
• Extensive ESD- and Surge-Protection
• Unit is Mains fed via an EU-type power plug.
• High output level low power consumption
