M AR KER
6
No. Dis. Loss Ref.
dB/km C.Loss
A-B: 000.000km 0.000dB 0.000dB/km
A 0.000km
B 0.940km
4.00dB/div
X Y
0.200km/div
201001.sor
Measure Info: 1310nm 2.0km 10ns
1/6
3/6
4/6
5/6
0.000
4.301
5.589
18.712
0.00
0.12
-0.05
-.-- -.-- -.--
-.--
-.--
-51.74
-54.67
-41.03
0.28
0.22
0.00
1.18
4.07
2/6
0.940 0.08 -51.74 0.24 0.26
2020-10-01 THU 21:25
After testing or open the saved waveform, then event list shows, Max. 5
events listed, if more, press “ ”“ ” to view, and the cursor will be
located in selected event, short press “ ” to choose the cursor, and
scale current waveform by pressing combined buttons.
Mini OTDR--Waveform Analysis
X-axis zoom in
A
B
2
3
0.000km
10.057km
Y-axis zoom in
A 0.000km
1
B 10.057km
2
3
To Next Page
