TECH-SUPPORT@TRICKSTUFF.DE SERVICE MANUAL – DIRETTISSIMA/MAXIMA PUMP V2024_02. PAGE 26 OF 27
10. Check the lever blade movement for unwanted play. If detected, use the locking bolt on the
backside of the brake pump for adjustment:
1. Before trying to move the bolt, use a heat gun to warm the bolt to release the thread
locker.
Note: Be careful when inducing heat, to not damage the nearing bearings.
2. After heating it up, remove the locking bolt with a HEX1.5 key and apply high strength
thread locker (e.g. Loctite 648) before mounting it again.
Note: In this bore, there is a small plastic ball, which gets deformed against the threads of
the piston rod. This eliminates play in the lever movement. Apply torque to the locking bolt
until the play is gone, but only so much that it doesn’t prevent you from manually turning
the dial.
