Dryspell Series Instruction Manual
Statement of conformity
97/23/CE : Pressurised Equipments
89/392/CEE : Machine Safety
89/336/CEE : Electromagnetic Compatibility
73/23/CEE : Low Voltage
Specification
Maximum Pressure : 225 PSIG (16 bar)
Minimum Pressure : 29 PSIG (2 bar)
Maximum Temperature : 158 F
Voltage : 115/1/60, 208-230/1/60, 220-240/1/50
Power Consumption : 12 Watt Max
Recommended
Pre-filter rating : 0.01 Micron (Coalescer)
After-filter Rating (Inbuilt) : 3.0 Micron (within the diffuser screen or Compactor plate)
Cycle Time : 4 min
Purge Loss : 12%
Air Outlet Conditions : Dry air down to -40degF ADP
Power Cord : 7 ft
Contents
The dryer consists of:
2 aluminum towers filled with desiccant
2 aluminum blocks including air seals and check valve
1 Pre filter
2 solenoid pilot valves
Built in after filters
1 electronic control
1 pressure gauge
2 Mufflers
Electronic auto drain
Adsorbent Material
The desiccant used in the dryspell series is a smooth sphere of activated alumina produced
by a unique manufacturing process. The benefits of using this high performance desiccant
include:
Uniform ball size
Reduces pressure drop and channeling
High crush strength
Allows rapid pneumatic loading of towers
