Trident Dryspell Series - Changing the Desiccant; Dryspell 10 to Dryspell 60 A; Dryspell 100 to Dryspell 375

Dryspell Series Instruction Manual
The total quantities required for each model are as follows (weight in kgs):
Dryspell Models
Quantity (
Kgs
)
10 2
20 6
30 8
45 10
60 A 14
100 8 Bag*
125 10 Bag
200 16 Bag
250 20 Bag
300 24 Bag
375 30 Bag
*Bag is a special custom made desiccant cartridge. It is accurately packed and sealed with a
required quantity and quality of desiccant.
Changing the Desiccant
1. Dryspell 10 to Dryspell 60A
 Bypass dryer.
 Disconnect dryer from airlines.
 Loosen the Tie rod and remove it
 Replace the old desiccant
 Make sure O-rings or gaskets are in place
 Install and screw the Tie rod
2. Dryspell 100 to Dryspell 375
 Bypass the dryer.
 Disconnect dryer from air lines.
 Loosen the M8 Allen Bolt and remove the top block and top compactor plate.
 Remove the saturated desiccant bag by pulling the bag handle in upward direction and
replace the new desiccant bag. If there is no desiccant bag, just tilt the dryer remove
the old desiccant and replace new desiccant bag.
 Make sure O-rings or gaskets are in place
 Install the top compactor plate continues by top block and screw the M8 Allen Bolt.
R1 - 06/13
