Installation
Step 1: Installing the Antenna
Note: To minimize any interference to the GPS signal, make sure that the GPS antenna is at least 2 m (6 ft) from
any other antenna (including a radio antenna). You may experience interference if you operate the vehicle within
100 m (300 ft) of any power line, radar dish, or cell phone tower.
Installing the Patch Antenna
Find the mounting location for the antenna at the front of the vehicle roof, centered from left to right.
On the mounting plate, remove the protective covers from the adhesive strips.1.
Attach the mounting plate to the vehicle roof with the adhesive strips. Ensure that the mounting plate is
centered along the vehicle roof.
2.
Place the antenna directly on the mounting plate. The magnet on the bottom of the antenna will hold it in
place.
3.
Route the antenna cable into the cab.4.
Note: For optimum performance, always use the metal antenna mount plate.
Installing the Ag15 Antenna
If you have upgraded to the Ag15 antenna, find the mounting location for the antenna at the front of the vehicle
roof, centered from left to right.
On the mounting plate, remove the protective covers from the adhesive strips.1.
Attach the mounting plate to the vehicle roof with the adhesive strips. Ensure that the mounting plate is
centered along the vehicle roof.
2.
Connect the antenna cable to the antenna.3.
Place the antenna directly on the mounting plate. The three magnets embedded in the bottom of the
antenna will hold it in place.
4.
Route the antenna cable into the cab.5.
Step 2. Attaching the Lightbar Cables
The lightbar with the basic antenna and power configuration:
9
