PartsoftheR10receiver
Alloperatingcontrolsarelocatedonthefrontpanel.Serialportsandconnectorsarelocatedonthe
bottomoftheunit.
Frontpanel
ThefollowingfigureshowsafrontviewoftheR10receiver.Thefrontpanelcontainsthefour
indicatorLEDsandthePowerbutton.

ThePowerbuttoncontrolsthereceiver’spoweronorofffunctions.SeePowerbuttonoperations.
TheindicatorLEDsshowthestatusofpower,satellitetracking,andradio
reception.SeeLED
behavior.
Lowerhousing
ThefollowingfigureshowsthelowerhousingoftheR10receiver.Thehousingcontainsthetwo
serialports,oneTNCradioantennaconnector,theremovablebatterycompartment,andthe5/8‐
11threadedinsert.
Eachportorconnectorismarkedwithanicontoindicateitsmainfunction,asshowninthe

followingtable:
Receiverports

Icon Name Connections
 Port1 Device,computer,externalradio,powerin
 Port2 Device,computer,externalradio
 RADIO Radiocommunicationsantenna

Port1isa7‐pin0‐shellLemoconnectorthatsupportsRS‐232communicationsandexternalpower
input.Port1hasnopoweroutputs.
Port2isaDB‐9maleconnectorthatallowsforfull9‐pinRS‐232communications.Port2doesnot
supportpowerinorout.
Formoreinformationondefaultportsettings,seeDefaultreceiver
settings.
TheTNCportconnectorisforconnectingaradioantennatothereceiverinternalradio.Awhip
“rubberduck”antennaissuppliedwiththesystemforunitswithinternalUHFor900MHzradios.
Thisconnectorisnot
usedifyouareusinganexternalrad ioreceiver.Forlongerrangeoperation(to
providehighergainandtoraisetheantennahigherabovetheground),youcanuseacableto
connectanexternalradioantennatotheTNCport.Formoreinformation,seeConnectingthe
receivertoexternaldevices

