Trimble R10 User Manual

TrimbleR10ReceiverWebHelp
Receivermode Power
button
RadioLED Satellite
LED
DataLED Wi‐Fi
LED
Transferringdatatothumb
drive
N/A N/A N/A Slowflash N/A
Alldatatransferredto
thumbdrive
N/A N/A N/A Veryslow
flash
N/A
Thumbdrivefull N/A N/A N/A Fastflash N/A
Wi‐Ficonfiguredasan
AccessPoint
N/A N/A N/A N/A Slow
flash
Wi‐Ficonfiguredasaclient N/A N/A N/A N/A On
Receiverinmonitormode ? ? ? ? ?

{b}Note–{/b}Ifacolumnshows“N/A”,thatspecificLEDmayormaynotbeon,butitisnot
relevanttothatparticularmode.
Connectingtotheofficecomputer
{b}Note–{/b}SPS985only
Thereceivercancommunicatewiththeofficecomputerusingaserialconnectionbyeitherusing
theUSBtoSerialCable(P/N87144),orbyusingtheUSBcable(P/N80751‐HH)andthen
ConfiguringaPCUSBportasavirtualserialport.Beforeyou
connecttotheofficecomputer,ensure
thatthereceiverbatteryisfullycharged.

DefaultSettings
Defaultreceiversettings
Thesesettingsaredefinedinthedefaultapplicationfile.

Function Settings Factorydefault
SVEnable‐AllSVsenabled
Elevationmask 10°
PDOPmask 25
RTKpositioning
mode
LowLatency
GeneralControls
Motion Kinematic

Trimble R10 Specifications

General

Channels	440
RTK Horizontal Accuracy	8 mm + 1 ppm RMS
RTK Vertical Accuracy	15 mm + 1 ppm RMS
Operating Temperature	-40 °C to +65 °C
L1 C/A Code	Yes
L2E	Yes
L2C	Yes
L5	Yes
Beacon	No
FM Radio	No
WAAS	Yes
MSAS	Yes
EGNOS	Yes
Storage Temperature	-40 °C to +75 °C
Ingress Protection	IP67
Positioning Accuracy (Static) - Horizontal	3 mm + 0.5 ppm RMS
Positioning Accuracy (Static) - Vertical	5 mm + 0.5 ppm RMS
Signal Tracking	BeiDou
RTK Initialization	< 8 seconds
Battery Life	Up to 7 hours
SBAS Accuracy	50 cm
Glonass Code	L1 C/A, L2 C/A
Communications	Bluetooth
