permissions.Administratorscanusethisfeaturetolimitaccessto otherusers.Securitycanbe
disabledforareceiver.However,Trimblediscouragesthisasitmakesthereceiversusceptibleto
unauthorizedconfigurationchanges.
Firmwaremenu
UsetheFirmwaremenuto verifythecurrentfirmwareandloadnewfirmwaretothereceiver.You
canupgradefirmwareacrossanetworkorfromaremotelocationwithouthavingtoconnecttothe
receiverwithaserialcable.
Helpmenu
TheHelpmenuprovidesinformationeachofthereceiversettingsavailableinthewebbrowser.
TheHelpfilesarestoredontheTrimbleInternetsiteandupdatedbetweenfirmwarereleases.For
example,www.trimble.com/EC_ReceiverHelp/v4.60/en.ForlanguagesotherthanEnglish,replace
enwiththeappropriatetwo‐lettercountrycode(seeabove).
ToaccesstheHelp,yourcomputermustbeconnectedtotheInternet.Ifyoudonothaveaccessto
theInternet,thereisalsoacopyofthereceiverHelpfilesonthe
supportareaoftheTrimble
website(www.trimble.com/support.shtml
).
ReceiverStatusmenu
ReceiverStatus–Identity
ThispageshowsinformationabouttheidentityoftheTrimblereceiver.
SystemName–Providesawaytodistinguishbetweenreceivers.IntheSystemNamefieldatthe
bottomofthescreen,enteralogicalnametoidentifythereceiversuchas"WorkSiteAlphaRxr".To
helprecognizethereceiverwhen
usingtheZeroConfigurationservicediscovery,enteranamethat
isclearandobvious.Thisnameisvisiblewhenonacomputerthatisonthesamesubnetasthe
receiver.Youshouldplantheassignmentofsystemnames,especiallyinlargenetworks,tohelp
networkadministration.
SerialNumber–Showstheserialnumberofthe
Trimblereceiver.Thisnumberisuniqueacrossall
Trimblereceivers,andisthemostreliablewaytoidentifyaspecificreceiver.
EthernetMACAddress–ShowstheEthernetMAC(MediaAccessControl)Address,whichisan
Ethernethardwareaddressthatuniquelyidentifieseachdeviceonanetwork.TheTrimblereceiver
hasauniqueaddressandyoucanuseittodistinguishbetweenmultiplereceiversonanetwork.
EthernetIP–ShowstheEthernetIPaddressassignedtothereceiver.Thisaddressisusedto
connecttothereceiverusingtheEthernetport.Thisaddressmaybestatic,oritmaychange
over
time(DHCP),dependingontheEthernetconfiguration
ofthereceiver.
DNSAddress–ShowstheIPaddressoftheDNSserver.
SecondaryDNSAddress–ShowstheIPaddressofthesecondaryDNSserver.
DNSresolvedname–ShowstheDNS(DomainNameSystem)name,whichisanalternatewayof
addressingthereceiveronthenetwork.
Thenameisused asanaliasfortheEthernetIP.Itisa
