TrimbleR10ReceiverWebHelp

 L2Integers–ThestatusoftheintegerresolutionforeachsatelliteontheL2frequencyusedin

theRTKsolution.R=Resolved,F=Float

 L5Integers–ThestatusoftheintegerresolutionforeachsatelliteontheL5frequencyusedin

theRTKsolution.R=Resolved,

F=Float

 L1C/No[dBHz]–Thisisthesignal‐to‐noiseratio(SNR)forthesatellite.

 L2C/No[dBHz]–ThisistheSNRforthesatellite.

 L5C/No[dBHz]–ThisistheSNRforthesatellite.

GoogleEarth

Tousethisfeature,youmusthaveGoogleEarth4.1orlaterinstalled.TodownloadGoogleEarth,

gotohttp://earth.google.com/download‐earth.html

.

UsetheGoogleEarthmenutoopenGoogleEarththroughalinkinthereceiver.Thissetsupa

networklinkbetweenthereceiverandGoogleEarth.GoogleEarthshowsthecurrentpositionof

thereceiver;thisisrefreshedevery30seconds.

ToopenGoogleEarth,click

andthenclickOK.WhenGoogleEarthopens,youwill

seeaplacemarkershowingthecurrentpositionofthereceiver.

{b}Note–{/b}Ifyouhavesecurityenabled,enteryourusernameandpasswordforthereceiver's

webinterfaceintotheGoogleEarthloginbox.

Oncethedatahasloadedinto

GoogleEarth,itshouldlooksimilartothefollowingscreen.Thepoint

nameshownistheserialnumberofthereceiver:



Every30seconds,thepositionoftheplacemarkerupdateswiththecurrentpositionofthereceiver.

ClicktheplacemarkerinGoogleEarthtoviewinformationaboutthecurrentposition

andthe

numberofsatellitestracked.

Thereceiverprovidesyouwiththeoptionofsendinguptoapproximately200bytesofHTMLtothe

placemarker(shownwhenyouclicktheplacemarker).Thisinformationmustbewell‐formedHTML

andcanbeusedtoprovidelinkstootherwebpagesand/or

animageofthereceiver.

{b}Note–{/b}Version4.10ofGoogleEarthdoesnotallowyoutouseiframes.Anexampleisshown

ofwhatcouldbeaddedtotheHTMLfieldinthereceiver,where“myServer”isawebserver:

<imgwidth=“500”src='http://myServer/AntennaLocation.png'></img>

Then,whenyouclicktheplacemarker

italsodown loadsandshows“AntennaLocation.png”,as

showninthefollowinggraphic.Approxi matelyevery30secondstheplacemarkerdisappearsas

GoogleEarthrefreshestoshowthereceiver'sposition.


