Trimble R10 - Satellites - Tracking Information (Graph); GPS Satellite Enable;Disable

TrimbleR10ReceiverWebHelp
IODE(IssueofDataEphemeris)–Thenumericidentifierforthelatestephemerisdatacollected
fromthissatellite.
URA[m](UserRangeAccuracy)–Thesatellite's e stimateoftheaccuracyofitsrangingsignals,in
meters.
Type–Indicateswhichsatellitemodelorgeneration
isbeingtracked(ifknown).
Satellites–TrackingInformation(Graph)
Thisgraphshowsinformationaboutthesatellitesthatarecurrentlytracked.
Toviewthegraph,yo uneedSVGsupport
.
ThegraphcanbesortedbasedonthesatelliteIDortheelevationangle.Tochangetheordering
sequence,clickOrderbybelowthegraph.
Type–Applyafilterbyselectingordeselectingthetypeofsatelliteandfrequencydisplayed.For
dual‐antennasystemsyoucanselectboth
thepositionandvectorantennafrequencies.
SV–Thenumericidentifierofthesatellitetrackedonthechannel.
C/No–TheSNRofthesatelliteontheselectedfrequencies.Scaledtoa1Hzbandwidth.
Elev[Deg]–Theelevationofthesatellite,indegreesabovethehorizon.
Satellites–TrackingSkyplot
Thisplotshowsthelocationsofthesatellitesthatarecurrentlybeingtrackedcenteredonthe
receiver'santennalocation.
Toviewthegraph,yo uneedSVGsupport .
Thenumbersontheoutermostcircleindicatetheazimuthanglevalues.
Thenumbersoneachoftheinnercirclesindicatetheelevationanglevalues.
Thecolorofthesatellitessignifyitstrackingstatus:
 Blue–TrackingGPSsatellite
 Red–TrackingGLONASS
 DarkGreen–Trackingan
OmniSTARsatellite
 Green–TrackingSBASsatellite
 Gray–Satelliteisaboveelevationmaskbutitisnotyetbeingtracked
 Yellow–TrackingGIOVEorGalileosatellites
GPSSatelliteEnable/Disable
AseparatepageisavailableforeachtrackedconstellationsuchasGPS,GLONASS,andGalileo.
