Trimble R10 - Satellite Ground Track; Rise;Set (Table)

TrimbleR10ReceiverWebHelp
 Red–GLONASSsatellites
 Magenta–GIOVE/Galileosatellites
 Greencircles–Visiblesatellites
 Yellowdot–Currentreceiverposition
SatelliteGroundTrack
Usethispagetoviewanorbitofagivensatelliteprojectedontotheearth.Thegraphshowsthe
currentpositionofthesatelliteandthetime(inUTCformat)thatitwillpassovervariouslocations.
Toviewthegraph,yo uneedSVGsupport
.
SelectthesatellitetypefromthelistofavailableconstellationsandID:
 Thecurrentlocationoftheselectedsatelliteabovetheearthisshownbyinred.
 TheUTChourisshownforeachlocationalongtheorbit.
 ThecurrentReceiverpositionisshownasa
yellowdot.
 ThesatelliteisvisiblefromtheReceiverpositionwhentheorbitisgreen.
 ThesatelliteisnotvisiblefromtheReceiverpositionwhentheorbitisblue.
Rise/Set(Table)
ThistableprovidestheUTCtimeatwhichthesatellitescurrentlybeingtrackedbythereceiverwill
riseaboveandsetbelowtheselectedelevationmaskattheselectedlocation.
IgnoreHealth–Selectthischeckboxtoviewbothhealthyandunhealthysatellitesinthe
predictions.
ElevationMask–Enter
theminimumelevationthatyouwanttocomputethesatellitesrise/set
times.Theriseandsettimesarebasedonwhenthesatellitesmeetsthiscriteria.
UseReceiverPosition–Selectthischeckboxtousethecurrentreceiverlatitude/longitudeto
computerise/settimes.
SelectPositionfroma
list–ThisoptionbecomesavailableonceyoucleartheUseReceiverPosition
checkbox.Thisenablesyoutoselectamajorcityfromthelist.Toview therise/settimesfora
particularlocation,clearthecheckbox.Fieldsthenappearwhereyoucanenterthelocation's
latitudeandlongitude.

ClickUpdatetoshowthepredictionsbasedonthedataselected.
Rise/Set(Graph)
SatelliteType–Selectthetypeofsatellitestoviewtheriseandsettimesfrom.
IgnoreHealth–Selectthischeckboxtoviewbothhealthyandunhealthysatellitesinthe
predictions.
