AutoDelete–Ifthischeckboxisselected,thereceiverautomaticallydeletefileswhenthe
availablespacedropsbelow500Kbytes.Thereceiverdeletestheoldestfilesfirst.Ifthischeckbox
isnotselected,alldataloggingstopswheneverthereisinsufficientavailablespacefor
newdatato
belogged.Changestakeeffectimmediatelyafteryouselectthecheckbox.
Session–ThisfieldshowstheGNSSMeasurementsandPositionstorageintervalsandaConfigure
button.ClickConfiguretoopentheDataLoggingConfiguration
pagetoviewandeditthecomplete
sessionconfiguration.
Schedule–Showsthetypeofschedule
configuredforthesession.
Status–Showsthecurrentstatusofthesession.Ifthesessionisactivelyloggingdata,thenthe
pathnameofthefileisshown.Otherinformationmaybeshown,dependingonthesession
configuration.ClickthenameofanactivefiletoswitchtotheData
Filespageshowingthedirectory
containingthatfile.
Enable–Selectthischeckboxtoimmediatelyenablethesession.Depend ingonthesession's
schedulemode,loggingmightnotstartimmediately.Ifyouclearthecheckboxonanactive
session,youareaskedtoconfirmthatyouwanttostopthe
session.
DataFiles
Usethefirsttabletonavigatearoundthefilesystem.Theto prowshowsthepathtothedirectory
youareviewing.Clickthatpathtorefreshthepagetoshowanyrecentchanges.Therowsbelow
thatenableyoutomoveupwardordownwardinthedirectorystructure.
Togo
tothetopofthefilesystemstructure,clicktheHomeiconorTopLevelDirectory.
Togouponelevel,clickParentDirectory.Anysubdirectoriesareshownbyname.Clickthemto
view.
Thepageshowsanydatafiles.Eachfileshowsthefilename,createddateandtime,
andsize.To
downloadthefile,clickthefileiconorfilename.Eachfilehasacheckboxthatyoucanusetoselect
itfordeletion;Toselectalloftheshownfilesfordeletion,clicktheiconnexttotheSelectAll
button.Todeletethefiles,clickthe
iconnexttotheDeleteSelectedFilesbuttonandthenclickOK
toconfirmthedeletion.
Todeleteallfileswithinthesubdirectory,clickXonthesubdirectoryandthenclickOKtoconfirm
thedeletion.
Afilethatisactivelybeingwrittenappearsinthelist,butcannotbe
downloadedorselectedfor
deletion.Typically,thenameisnotshowninboldandtheDeletecheckboxdoesnotappear.
Graph(icon)‐TheGraphfunctionopensthePosition(Graph)andplotstheHeight,East,Northor
East/Northdatafromthepositionrecordsofthe*.T01or*.T02files.
Formore
information,seePosition(Graph).
Convert‐ClickConverttoconverttherawdatalogg edinaT01orT02filetoanumberofdifferent
formatsincludingRINEX,BINEX,andGoogleEarth(KML).
RINEXConversion‐T01andespeciallyT02filesaremorecompactthanRINEXfilesandholdmore
information.UsetheRINEXconverterif
yourequireanindustrystandardfileformat.Theconverter
doesadataconversionon‐the‐flywhentheuserrequestsaRINEXdownload.Asthisisdoneina
singlepassandthereisnowaytopredictthesizeofthefile,theonelimitationisthesizeof
thefile
