2
Device Hardware
Front Panel Back Panel
Removable CF-Cap covers two
CompactFlash slots and one SD slot
CF-Cap
Top View- without Cap
Bottom View
CompactFlash and SD card slots
NOTE: Be sure to read the warranty and safety information in this
manual prior to using your unit.
PowerBoot
coin screws
PowerBoot
Module
Stylus
holder
Power
Serial
port
USB
host
CF slot #1
type I
External
power
USB
client
CF slot #2
type I & II
SD
Notification
LED
Hand strap
