Trimble TSC3 - Technical Specifications; Environmental and Hardware Details

37
Environmental Specifications
TEMPERATURE
WWAN UNITS
Operation: -22 °F to +140 °F (-30 °C to +60 °C)
Storage: -40 °F to +158 °F (-40 °C to +70 °C)
Operation: -4 °F to +140 °F (-20 °C to +60 °C)
Storage: -4 °F to +122 °F (-20 °C to +50 °C)
SHOCK
MIL-STD-810G, Method 503.5
HUMIDITY
MIL-STD-810G, Method 507.5
WATER
IP67, sealed against accidental immersion (submersible to 1
meter for 30 minutes)
DROP
MIL-STD-810G, Method 516.6, Procedure IV
26 drops @4 ft. (1.22 m) onto plywood over concrete; 6
drops @-22 °F (-30 °C), 6 drops @+140 °F (+60 °C)
SAND AND DUST
IP67, sealed against dust
VIBRATION
MIL-STD 810G Method 514.6, Procedure I & II
ALTITUDE
MIL-STD 810G, to 15,000 ft (4572 m) at a nominal temp. of
+73 °F (+23 °C), Method 500.5, Procedures I, II, & III
EMI
Meets FCC class B requirements
ROHS COMPLIANT
This product complies with international RoHS regulations
Hardware Specifications
OS
Windows Mobile 6.5 Professional
CPU
Texas Instruments Sitara® AM3715 ARM® Cortex™ A8
RAM (VOLATILE)
256 MB DDR SDRAM
FLASH STORAGE
8 GB of nonvolatile NAND Flash storage
DISPLAY
640 x 480 VGA (4.2” landscape), sunlight-readable color
TFT with resistive touchscreen and LED backlight
KEYPAD
Qwerty or ABCD
BATTERY LIFE
34 hours with unit on, but idle, backlight on, all radios off,
compass off and using a new battery.
BATTERY CHARGING
3 hours to full charge
BATTERY CAPACITY
11.1 V, 2600 mAh, 28.9 Wh Li-Ion rechargeable pack
POWER SUPPLY
SL Power PW173KB
POWER
Input: DC 15.0 V 2.0 A
I/O PORTS
Mini-USB client, USB host, Audio Jack, Serial Port (9-pin RS-
232), SDHC Memory slot, SIM slot
SOUND
Integrated sealed speaker and microphone. Audio jack is for
a headset with stereo speaker and microphone
ADDITIONAL FEATURES
Color Digital Camera (5 megapixel) with Auto Focus and
Flash, Laser Barcode Scanner, Digital Compass with
Accelerometer
INTEGRATED WIRELESS
All units have Integrated GPS
Optional 3G GSM (pentaband HSDPA), Wi-Fi 802.11B/G and
Bluetooth 2.0+EDR
