ASSEMBLY INSTRUCTIONS
Carefully flip completed cart right side up.
TBFLWH-1403 only
Place TRAY (K) onto SHELF (B).
Flip cart over and lay WOOD TOP
FRAME (A) top surface on a clean
surface again. Screw CASTER (F) into
the nut at the bottom of CASTER LEG
(C). Tighten CASTER (F) with WRENCH
(J).
Use the provided caster wrench to
tighten completely. Failure to do as
instructed could result in the caster
stem breaking.
© 2016 TRINITY - 800.985.5506
4
STEP 5
STEP 6
F (2) J (1)
K (1)
TBFLWH-1403 only
TBFLWH-1402 TBFLWH-1403
F
J
K
