Trinity TBFZ-2702 - Step 9: Add Sidebars with Hooks

ASSEMBLY INSTRUCTIONS
© 2016 TRINITY - 800.985.5506
7
Locate the desired position and place a pair
SLIP SLEEVES (J) onto the pole.
Slide the SIDEBAR W/ HOOKS (I) down, over
the SLIP SLEEVES (J).
STEP 9
J (2)I (1)
J
I
