Trion MA600 - Specifications Data Table

TRION AIR BOSS Mist Arrestor 3-Stage Mist Collector
Specifications Data Table
MA 600 MA 1200
Dimensions: 74.2” L x 27.6 ” W x 333.1” H 70.3” L x 27.6 ” W x 35.8” H
1885mm x 700mm x 840mm 1785mm x 700mm 910mm
Weight: 331 lbs/ 150 kg 437 lbs/ 198 kg
Motor: 3 Hp / 2.2kw 4 Hp / 3.0kw
Amp Draw: 208V – 8.8 amps 208V – 11.9 amps
230V – 7.9 amps 230V – 10.7 amps
460V – 4.0 amps 460V - 5.4 amps
Air Inlet Single 6” Diameter Single 8” Diameter
Air Volume: 600 CFM @ 6.0” SP 1200 CFM @ 6.0” SP
Sound Rating: 72 dBa 72 dBa
Filters:
Prefilter Washable 12 Layer Coalescing Filter-99% @ 2 micron size +
Initial Resistance: 2.75” w.g. Final Resistance: 4.0” w.g.
12” x 12” x 4.0” 12” x 24” x 4.0”
295 x 295 x 80mm 295 x 595 x 80mm
Secondary Washable 7 Layer Coalescing Filter-99% @ 10 micron size +
Initial Resistance: 0.4” w.g. Final Resistance: 1.25” w.g.
12” x 24” x 5.5” 24” x 24” x 5.5”
295 x 595 x 150mm 595 x 595 x 150mm
Primary Mini-Pleat Extended Surface Filter, 98% Ashrae, 194 sq.ft. media
Initial Resistance: 0..56” w.g. Final Resistance: 2.0” w.g., Class 2
12” x 24” x 12” 24” x 24” x 12”
292 x 592 x 292mm 592 x 592 x 292mm
Common Specifications:
Cabinet: 16 gauge Galvanized Steel
Doors: Gasket sealed, Hinged Access doors on primary, secondary
and final filters and blower access compartment.
Drain: 3 / 4” NPT x 2” centered behind secondary filter
Finish: Textured Reverse Blue, Baked on Oil Resistant Paint
Installation: Ducted to Platform or Frame Mounted
Manometer Gage: Installed with 2 each Manometer Pressure Gage Kit, 0-6.4” wg
Electrical: 208-230/460V/60Hz/3 PH, junction box provided
Blower: Direct Drive centrifugal
Blower Access: Removable Rear Panel and side access door
Options:
Controls: Motor Starter provided by Customer
FIG. 3
