Actuator replacement
Maintenance
12
Actuator replacement procedure
1. Unscrew the 2 bolts holding the defective seat (under foot rest)
2. Flip seat back (protect head rest by covering floor with something soft)
3. Remove cover plate between the 2 seats
4. Open cover of control box, and detach the actuators’s 2 connectors
from the
control box board (see page 38)
5. Remove front cover plate from control box
