Triotech TYPHOON - Actuator and Drive Assembly Repair; Actuator Removal and Reinstallation Process

Actuator replacement
Maintenance
12
Actuator replacement procedure
6. Unscrew the 4 hex socket screws from inside the actuator positioning
hole
7. Unscrew the 5 hex socket screws attaching the actuator to the seat
frame
8. Remove actuator
9. Reverse procedure to re-reinstall new actuator
