23
Using the HOUND Jr, trace the wire through the
wall by following the strongest warble TONE
pickup. (See Figure 3)
FLOOR
SPEAKER
WIRES
DOORWAY
ADDITIONAL
SPEAKER
WIRES
SEVERAL
SPEAKER
WIRES
MOMEMTARILLY
SHORT ENDS TO
“KILL” TRACER TONE
Figure 3
