3
SPECIFICATIONS
All surge suppressors listed have component response times of less than 1 picosecond.
Model: Description:
Nominal
Clamping Voltage:
Peak Pulse
Current:
DRS232
RJ45/RJ11 protector for
100Base-T4, RS232 on twisted Pair
(wires 1-8) or ISDN “S/T” interfaces.
Supplied with a 4” RJ45 patch cable.
18 volts, protecting
wires 1-8
1340 amps
DNET1
RJ45 100Base-T, 10Base-T,
Token Ring, RS422, AS400/Sys3x
protector for NICs, hubs, routers,
etc. Supplied with 4” RJ45 patch
cable.
7.5 volts, protecting
wires 1-8
750 amps
DSUT1CSU
RJ45/RJ11 protector for nonspan
powered T-1 equipment, digital data
service CSUs/DSUs, ISDN “U”
interfaces or other digital lines.
Supplied with 4” RJ45 patch cable.
60 volts, protecting
wires 1-8
200 amps
DTEL2
RJ45/RJ11 for modems, answering
and fax machines. Supplied with
4” RJ11 patch cable.
260 volts, protecting center
4 wires (2 CO-lines)
250 amps
DB9
Serial DB9 RS232 protector for male
or female ports of data terminal and
computing equipment including PCs,
modems, etc. (Any male or female
9-pin port). Male/Female genders
are reversible with reversible
thumbscrews.
18 volts, protecting pins
1-9 and chassis
340 amps
DB25
Serial DB25 RS232 protector
(wires 1-8, 20) for male or female
ports of data terminal & computing
equipment including PCs, printers,
modems, etc. Male/Female genders
are reversible with reversible
thumbscrews.
18 volts, protecting pins
1-8, 20 and chassis 340 amps
DB25-ALL
DB25-ALL: Serial DB25 RS232
protector (pins 1-25) for any 25-pin
male or female DTE/DCE ports.
Male/Female genders are reversible
with reversible thumbscrews.
18 volts, protecting pins
1-25 and chassis
340 amps
D10B2
10Base-2 thin coax protector (BNC
m/f). Also protects IBM 3270 and
CCTV lines.
7.5 volts, protecting center,
shield and chassis
750 amps
DCATV
Coaxial protector for TVs, VCRs, pro
video supplied by CATV (“F” m/f).
7.5 volts, protecting center
and shield conductors
750 amps
Call Tripp Lite Customer Support at (773) 869-1234 for additional applications.
