Tripp Lite DMA1327SD - Installation

4
Installation
1. Assemble VESA Bracket Bars
2. Slide VESA Head Brackets onto VESA Bracket Bar
Mounting
Plate
Bracket Bar Coupler
M6X30 Screw
4 mm Hex Key
VESA
Bracket Bar
End
Cap
VESA
Head
Bracket
6 mm
Hex Key
End
Cap
Screw
