Assembly
2
Attach the Columns to the Base
H
H
P-C
Pin
Pin
I
I
Inner
Column
V
Pull the pin outward and lift the inner column upward at the same time until the inner
column is at the desired height. Release the pin to secure.
Using M8x30 screws (P-C),
attach the columns to the base.
Tighten
the Safety
Screw.
