Assembly
1
Assemble the Base
Using M8x40 screws (P-D) and the 5 mm hex key (P-N), attach the right base to the
middle base. Repeat this step for the left base.
Note: Lock the brakes on the casters to avoid any sudden movements during installation.
Each caster can be adjusted independently for fine adjustments. Slightly turn each caster
nut to lower or raise the base.
P
C
Q
P-N
P-D
A
B
P-O
