WARNING
• Make sure mounting screws are anchored into the center
ofthestuds.Useofastudnderishighlyrecommended.
• Installers are responsible to provide hardware for other
types of mounting situations.
• Installers must verify the supporting surface will safely
support the combined load of the equipment and all
attached hardware and components.
Assembly
2a
Mount on Wood Stud Wall
Find and mark the
exact location of
mounting holes
Screw the assembled
wall plate onto the wall
Drill pilot holes
W-C
W-A
1
2
3
50mm50mm
(2.2")(2.2")
O 4.5mmO 4.5mm
(O 3/16")(O 3/16")
