Safety
IMPORTANT SAFETY INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
This manual contains instructions and warnings that should be followed during the installation and operation of all
Tripp Lite Power Centers. Failure to heed these warnings will void your warranty.
• ThePowerCenterfeaturesaninternalprotectionthatwilldisconnectthesurge-protectivecomponentattheendofits
useful life but will maintain power to the load—now unprotected.
• DonotconnectthePowerCentertoanungroundedoutlet.Donotusewith2-wireextensioncordsoradapters.Donot
plugextensioncordsintothePowerCenter.
• ThePowerCenterisdesignedforindooruseonly.InstallthePowerCenterawayfromheat-emittingappliancessuchas
radiatorsorheatregisters.Donotinstallwhereexcessivemoistureispresent.
• Neverinstallelectricalwiringduringalightningstorm.
• Donotdrillintoanypartofthehousingoropenthehousingforanyreason.Therearenouser-serviceablepartsinside.
• Useofthisequipmentinlifesupportapplicationswherefailureofthisequipmentcanreasonablybeexpectedtocause
thefailureofthelifesupportequipmentortosignificantlyaffectitssafetyoreffectivenessisnotrecommended.Donot
usethisequipmentinthepresenceofaflammableanestheticmixturewithair,oxygenornitrousoxide.
Features
Circuit Breaker, Cord and Back Panels
Outlet Panel
Circuit Breaker & Cord Panel
A
Detachable Power Cord with Right-Angle Plug: connectsthePowerCentertoastandard3-wiregrounded120VAC
60Hzwalloutlet.Detachablecordsimpliesinstallation;right-angleplugpermitsequipmentandfurnituretobeplaced
flush against a wall.
B
Circuit Breaker:protectsagainstdangeroussystemoverload.IfthetotalloadonthePowerCenter’soutletsexceeds
12amps,thecircuitbreakerwilltripandpowerwillbeturnedoffattheoutlets.Reducetheloadbyunpluggingsome
devices.Depressthecircuitbreakertorestorepower.
C
Mounting Flange:allowsforsecuremounting(withuser-suppliedscrews)onanysuitablesurface,includingonawall
behindaatpanelTVscreen.Theusermustdeterminethetnessofthemountingsurfaceandtheuser-suppliedscrews
prior to installation.
Outlet Panel
D
“HDTV” Outlet:protectsanyatpanelTV(plasma,LCDorHDTV)againstsurgedamageandlinenoisedistortionon
theACline.TurnpoweronandoffatthisoutletwiththePowerSwitch.
E
“ACCESSORY” Outlet:protectsanyaccessory(receiver,player,etc.)againstsurgedamageandlinenoisedistortionon
theACline.TurnpoweronandoffatthisoutletwiththePowerSwitch.
F
“LINE OK” LED:indicatesthatnominalACpowerispresentwithnowiringfaultsdetected.WhenthisLEDis
illuminated,ACpowerissafeforconnectedequipment.
D
E
F
G
H
A
B
I
J
C
