4
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
3
Using the center-to-center spacing of the mounting holes, mark the locations for
installation.
4
Secure the remote to its permanent location with user-supplied hardware. Tighten by
hand to reduce the possibility of cracking the remote module at its mounting points.
5
Connect the remote’s wired connector to the inverter’s RJ11 port labeled “REMOTE”.
6
Set the inverter’s main power switch to the REMOTE (||) position.
7
Test the connection and operation by pressing the ON/OFF until the green status LED
shows on the remote module.
To operate your power inverter using the PINVRM Remote Manual, please refer to your
power inverter’s Owner’s Manual.
Installation
