8
G
Main Ground Screw: Connect to an earth ground or a vehicle
grounding system in order to properly ground the inverter. See
Battery Connection for instructions.
H
Remote Control Module Connector: All models feature a
6-conductor telephone style jack on the front panel for use with
an optional remote control module (Tripp Lite model PINVRM,
included with all models). The remote module allows the Inverter
to be mounted out of sight in a compartment or cabinet, while
operated conveniently from your vehicle’s dashboard. See
Mounting and Operation sections instructions for use of the
remote control module.
Not Shown:
Audible Alarm: The internal audible alarm activates when either a low
or high DC voltage condition exists.
Feature Identification
19-04-283-9338A1.indb 8 5/2/2019 3:49:30 PM
