Installation
2
Attach Rack Brackets to LCD Mounting Plate
3
Attach Assembly and LCD Panel to Rack
LCD Mounting Plate
Rack Brackets
M5x10
M5 Flat Washer
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Maintenance
• Check that the bracket is secure and safe to use at regular intervals (at least every three months).
• Please visit www.tripplite.com/support if you have any questions.
M6 Cage
Nuts
M6 Cup
Washer
M6x16
