IMPORTANT: Ensure all parts according to the component checklist have been received prior to installation. If any parts are
missing or faulty, visit www.tripplite.com/support for service.
Component Checklist
M5x10 (x8) M5 Flat
Washer (x8)
LCD Mounting Plate
(x1)
M6x16 (x8)Rack Bracket (x2) M6 Cage
Nuts (x8)
M6 Cup
Washer (x8)
Installation
1
Attach LCD Mounting Plate to LCD Panel
M5x10
M5 Flat Washer
LCD Mounting Plate
