4
Installation
8. After changing the DIP switches as desired, hold down the Reset
button until the LEDs quickly blink. If successful, the LED next to the
chosen setting will stay on.
9. Power on the unit by connecting the included USB 2.0 power cable
between the DC In port and your computer’s USB port or a USB
charger.
10. Connect the included USB 3.0 cable between the unit’s USB port
and the host computer’s USB port.
11. The unit is now ready to use.
RAID Mode
This unit can be set to function in one of three modes: JBOD, RAID1 or
RAID2. Each mode is described below along with their corresponding
DIP switch setting.
RAID Mode Description DIP Switch 1 DIP Switch 2
JBOD Allows access
to both drives
simultaneously
Down Down
RAID1 Creates
duplicate
drives for data
redundancy
Down Up
RAID0 Combines both
drives into one
larger drive to
improve system
performance
Up Up
