Triton T80 Easi-fit - User Manual

Questions and Answers

Z
zwestJul 28, 2025
Why is my Triton Shower heater water too hot?
- A
  Adrienne HaleJul 28, 2025
  If your Triton Shower heater is delivering water that's too hot, there might not be enough water flowing through it. Try increasing the flow rate using the temperature control, or clean/replace the blocked sprayplate in the showerhead. Also, check if stop valves are fully open and inspect the inlet filter for blockages. If the ambient water temperature has increased, readjust the flow rate to increase the flow or select the 'ECONOMY' power setting.
C
Charles LewisAug 2, 2025
Why is the water from my Triton T80 Easi-fit too cool or cold?
- J
  Joseph HansonAug 2, 2025
  If your Triton Shower heater is delivering water that's too cool or cold, try the following: * Reduce the flow rate via the temperature control. * If the water pressure is below the required minimum, and if tank fed, replumb to the mains water supply. * If mains fed, ensure the mains stop valve is fully open and there are no other supply restrictions while showering. * You can fit a pump to achieve the required minimum pressure. * If the ambient water temperature has decreased, readjust the flow rate to reduce the flow, or select the 'HIGH' power setting. * Electrical malfunction: have the unit checked by a qualified electrician or contact Triton Customer Service. * Safety cut-out operated: have the unit checked by a qualified engineer or contact Triton Customer Service.
U
uromeroAug 7, 2025
How to fix a Triton Shower heater that is inoperable and has no water flow?
- C
  Chad BallardAug 8, 2025
  If your Triton Shower heater is inoperable with no water flow, the power supply might be interrupted. Check the fuse or circuit breaker and renew or reset it. If the issue persists, consult a qualified electrician. There may also be a unit malfunction or power cut. Check other appliances. If necessary, contact your local Electricity Supply Co. or Customer Service to have the unit checked.
E
Elizabeth RossAug 12, 2025
What to do if the pressure relief device on my Triton T80 Easi-fit Shower heater has operated?
- P
  Pam MaldonadoAug 12, 2025
  If your Triton Shower heater's pressure relief device has operated, causing water to eject from the PRD tube, it could be due to a blocked showerhead. Clean or replace the blocked sprayplate in the showerhead and then fit a new PRD. Another cause may be a twisted or blocked flexible shower hose, so check for free passage through the hose and replace it if necessary, then fit a new PRD. Also, make sure the showerhead was removed during commissioning; if not, fit a new PRD and commission the unit with the showerhead removed.
A
alicia30Aug 17, 2025
What causes a Triton T80 Easi-fit Shower heater to fail to shut off?
- T
  tjuarezAug 17, 2025
  If your Triton Shower heater fails to shut off, it may be due to a faulty start/stop switch, which will need to be replaced. Alternatively, there could be debris in the solenoid, requiring the solenoid valve to be replaced.
P
Pamela ConleyAug 22, 2025
Why does the water temperature of my Triton Shower heater cycle between hot and cool?
- J
  Jeffrey BatesAug 22, 2025
  If your Triton Shower heater's water temperature cycles between hot and cool, it might be due to the heater cycling on the temperature limiter. Refer to the causes and solutions provided for the 'Water too hot' problem, such as adjusting the flow rate, checking for blockages, and addressing ambient water temperature changes. If the issue persists, contact Triton Customer Service.

Summary

Introduction and Safety

Important Safety Information

Crucial safety warnings and precautions for operating the electric shower.

General Guidance Notes

Essential guidelines and recommendations before proceeding with installation or use.

Installation Check List

A step-by-step checklist to aid in the correct installation of the shower unit.

Installation Guidance Categories

General Installation Notes

Covers general points like isolation, mounting, and cleaning for installation.

Plumbing Installation Requirements

Details on plumbing compliance, pipe flushing, and fitting requirements.

Electrical Installation Requirements

Guidelines for electrical safety, earthing, and circuit connection.

User Advice and Operation

General Advice to Users

Explains how the shower operates and provides usage tips.

Important Advice to Users

Critical advice on commissioning and cleaning to prevent damage and maintain warranty.

Product Specifications

Electrical Specifications

Details of power ratings, voltage, and circuit protection requirements.

Plumbing Specifications

Information on water supply, pressure, temperature, and connection types.

Materials and Approvals

Lists the materials used in the shower and relevant safety standards.

Dimensions and Entry Points

Unit Dimensions

Provides the physical measurements of the shower unit.

Water and Cable Entry Points

Illustrates the approved locations for water and electrical cable entry.

Detailed Electrical Requirements

Electrical Supply and Circuit Protection

Requirements for the electrical supply, consumer unit, MCBs, and RCDs.

Shower Siting

Siting of the Shower Unit

Guidance on choosing the correct location for the shower, avoiding hazards.

Water Regulations Compliance

Shower Head Positioning Rules

Ensuring shower head is positioned correctly to prevent backflow and comply with regulations.

Plumbing Installation

Water Inlet Connection

Instructions for connecting the water supply using compression fittings.

Pipework Preparation and Isolation

Steps for flushing pipework and fitting an additional stopvalve.

Electrical Installation

Supply Cable Securing and Entry

Guidance on routing, securing, and sealing the supply cable entry.

Fitting to Wall and Connecting Supplies

Water Inlet Connection Orientation

How to orient the water inlet for left or right entry fitting.

Permanent Electrical Connection

Connecting the shower to the fixed wiring of the electrical mains system.

Shower Unit Fitting Methods

Fitting Procedure Using Template

Steps for marking and installing the shower using a fitting template.

Replacing Existing Shower Unit

Procedure for removing the old unit and fitting the new one.

Electrical Connection Details

Terminal Block Configuration

Details on configuring the terminal block for left or right electrical entry.

Fitting the Shower Cover

Cover Securing and Knob Alignment

Steps for attaching the shower cover, ensuring proper knob alignment.

Shower Commissioning

Pre-Commissioning Checks

Ensuring correct settings before turning on power and water supplies.

Commissioning Procedure Steps

Procedure to flush the unit and ensure it's ready for normal operation.

User Operating Instructions

Starting and Stopping the Shower

How to start and stop the shower using the main controls.

Using the Power Selector

Explanation of the COLD, ECONOMY, and HIGH heat settings.

Adjusting Shower Temperature

Temperature Control Method

How to alter water temperature by adjusting flow rate via the temperature control.

Shower Operating Functions

Power Indicator and Safety Features

Details on the power indicator, temperature protection, and safety cut-outs.

Maintenance and Filter Cleaning

Filter Cleaning Procedure

Instructions for installers and service engineers to clean the inlet filter.

Troubleshooting and Fault Finding

Common Shower Problems and Solutions

A guide to diagnosing and resolving common problems with the shower.

Spare Parts Information

List of Spare Parts

Reference list of available spare parts for the shower unit.

Quick User Guide for Controls

Shower Controls Overview

A visual guide to the main controls for starting, stopping, and heat settings.

Service and Warranty Information

UK Service Policy

Procedure for contacting customer service for faults and repairs.

Triton Standard Guarantee

Details of the product guarantee, coverage, and exclusions.

Triton T80 Easi-fit Specifications

General

Power Ratings	8.5 kW
Water Connection	15mm compression
Temperature Control	Stabilised
Shower Head Spray Patterns	5
Maximum Static Pressure	10 bar
Energy Efficiency Class	A
Voltage	230-240V
IP Rating	IPX4
Cable Entry Points	Top, bottom, back
Water Entry Points	Top, bottom, back
Installation	Wall-mounted
Approvals	BEAB, CE
Water Pressure	Min: 1 Bar, Max: 10 Bar
Cable Length	Not supplied
