Triumph 45-6060W - Hardware Identification; Accessories Identification

HARDWARE IDENTIFIER
(To Scale)
©
2016 Escalade Sports
For Customer Service Call 1-888-996-2729
3
All Rights Reserved.
(Not to Scale)
ACCESSORIES IDENTIFIER
(Not to Scale)
!
WARNING:
CHOKING HAZARD
Small parts.
Not for children under 3 yrs.
H3 - 3.5 mm x 12 mm
Phillips Round
Head Screw
(8 pcs)
H1 - 6 mm x 28 mm
Allen Head Bolt
(12 pcs)
H2 - 6.5 mm x 18 mm
Flat Washer
(12 pcs)
T1 - Allen Wrench
(1 pc)
H4 - 3.5 mm x 14 mm
Phillips Round
Head Screw
(18 pcs)
A4 Felt Pads may already
be attached to A1R and
A2 - RED
LED Puck
(1 pc)
A1R -
RED
LED Striker
(1 pc)
A1B -
BLUE
LED Striker
(1 pc)
A3 - Puck
(2 pcs)
A4 - Felt Pad
(2 pcs)
A1B Strikers.
NOTE:
A5 - A/C
Adapter
(1 pc)
A6 - USB
Cable
(1 pc)
