Triumph Rocket 3 GT 2021 - Page 1016

978
5. Fit a new 32 x 42 x 4mm seal to the outside edge and a new 30 x 37 x 4mm to the
inside edge until they are flush.
4. Needle roller bearing
5. Seal, 32 x 42 x 4mm
6. Seal. 30 x 37 x 4mm
6. Fit the bearing sleeve to the needle roller bearing.
7. Fit the spacers to the inner edges.
8. Fit the flanged spacers to the outer edges
1. Sleeve
2. Spacer
3. Flanged spacer
