980
3. Fit the swinging arm bolt to the right hand side. Hold the swinging arm spindle and
tighten the bolt to 100 Nm.
1. Bolt
4. Engage service tool T3880103 into the slots of the crankcase right hand frame
adjuster and tighten to 3 Nm.
1. Frame adjuster
2. Right hand outrigger
