981
5. Engage service tool T3880103 into the slots of the crankcase left hand frame adjuster
and tighten to 3 Nm.
1. Frame adjuster
2. Left hand outrigger
6. Fit the crankcase right hand rear mounting bolt and tighten to 48 Nm.
7. Fit the crankcase left hand rear mounting bolt and tighten to 48 Nm.
8. Attach the rear brake hose P-clip to the swinging arm with a new fir tree clip.
1. Fir tree clip
2. P-clip
3. Rear brake hose
