1005
6. Slowly apply front brake lever to the handlebar and maintain that pressure for
approximately five seconds. Slowly release the lever, and leave for 30 seconds.
Repeat three times.
Brake Fluid Cap - Installation
1. Fit the insert to the diaphragm seal. Make sure the locating lug on the insert fits into
its hole in the diaphragm.
2. Fit the diaphragm and insert assembly to the reservoir cap. Make sure the holes for
the fixings are correctly aligned.
3. Fit the diaphragm and insert (if fitted) to the reservoir cap. Make sure the holes for
the fixings are correctly aligned.
4. Fit the fixings into the cap and diaphragm seal assembly.
1. Insert
2. Diaphragm seal
3. Locating lug
4. Hole for locating lug
5. Reservoir cap
6. Fixings
